12.2 Designazione motore
MOTORE / MOTOR / MOTOR / MOTEUR
BN 63A 4 230/400-50 IP54 CLF ... W FD 3.5 R SB 220SA ...
NUMERO DI POLI / POLE NUMBER / POLZAHL / N.bre POLES
2, 4, 6, 2/4, 2/6, 2/8, 2/12, 4/6, 4/8
GRANDEZZA MOTORE / MOTOR SIZE / MOTOR-BAUGRÖSSE / TAILLE MOTEUR
M
ME
1SC...3LB
K
63 - 71
BN
BE
56A...180L
TIPO MOTORE/ MOTOR TYPE / MOTORTYP / TYPE MOTEUR
M
trifase integrato / 3-phase integral / kompaktes Dreiphasen / 3 phasé compact
ME
trifase integrato, classe IE2 / 3-phase integral, class IE2 / kompaktes Dreiphasen, Klasse IE2 / 3 phasé compact, classe IE2
K
trifase compatto / three phase motor compact type / Drehstrom - Kompaktmotor / Moteur triphasè compact
BN
trifase IEC / IEC 3-phase / IEC Dreiphasen / 3 phasé IEC
BE
trifase IEC, classe IE2 / IEC 3-phase, class IE2 / IEC Dreiphasen, Klasse IE2 / 3 phasé IEC, classe IE2
12.2 Motor designation
CLASSE ISOLAMENTO / INSULATION CLASS
ISOLIERUNGSKLASSE / CLASSE ISOLATION
CL F standard
GRADO DI PROTEZIONE / DEGREE OF PROTECTION
SCHUTZART / DEGRE DE PROTECTION
IP55 standard (IP54 - autofr. / brake motor / Bremssmotor / moteur frein)
TENSIONE-FREQUENZA / VOLTAGE-FREQUENCY / SPANNUNG-FREQUENZ / TENSION-FREQUENCE
BN 27, BN 44 (motori speciali / special motors / Spezialmotoren / moteurs speciaux)
12.2 Motor Bezeichnung
FRENO / BRAKE / BREMSE / FREIN
TIPO ALIMENTATORE / RECTIFIER TYPE
GLEICHRICHTERTYP / TYPE ALIMENTATEUR
LEVA DI SBLOCCO FRENO
BRAKE HAND RELEASE
BREMSENTHANDLÜFTUNG
LEVIER DE DEBLOCAGE FREIN
M
K
BN
COPPIA FRENANTE / BRAKE TORQUE
BREMSMOMENT/ COUPLE FREIN
TIPO FRENO / BRAKE TYPE / BREMSENTYP / TYPE DE FREIN
M
FD, FA
K
FC
BN
FD, FA, BA
POSIZIONE MORSETTIERA / TERMINAL BOX POSITION
KLEMMENKASTENLAGE / POSITION BOITE A BORNE
M
ME
W (default), N, E, S
K
W (default), N, E, S
BN
BE
W (default), N, E, S
FORMA COSTRUTTIVA / MOTOR MOUNTING
BAUFORM / FORM DE CONSTRUCTION
M
ME
—
K
B5
BN
BE
B5, B14
CL H option
12.2 Désignation moteur
OPZIONI / OPTIONS
OPTIONEN / OPTIONS
ALIMENT. FRENO / BRAKE SUPPLY
BREMSVERSORGUNG / ALIMENT. FREIN
M
NB, SB, NBR, SBR
K
—
BN
NB, SB, NBR, SBR
R, RM
R
R, RM
23
