Cleaning the view window
To easily clean the view window to the working
chamber, you can fold the working chamber door
upwards.
1.
Have ready:
A wet cloth
n
A mild cleaning agent (optional)
n
2.
Open the working chamber door.
3.
Grab the working chamber door at the middle of
the lower edge and fold it upwards.
F . 71 – F
IG OLDING THE WORKING CHAMBER DOOR UPWARDS
4.
Clean the inside of the view window with a wet
cloth. If necessary, use a mild cleaning agent.
F
IG
5.
6.
7.
8.
Cleaning the multi-purpose com-
partment
Cleaning the multi-purpose compartment is important
because otherwise machining debris will damage
sensitive machine parts.
1.
2.
3.
4.
5.
Original Operating Instructions: R5
Version: 5/10/2019
R5 – Maintenance and do-it-yourself
. 72 – T (
HE VIEW WINDOW MARKED ORANGE
Grab the working chamber door in the middle of
the bottom edge and fold it downwards.
The working chamber door is locked in place.
Close the working chamber door.
If DentalCNC displays a message that you need to
fold down the working chamber door, the door is
not completely fold down. Repeat steps 5 and 6.
If necessary, clean the outside of the view win-
dow with a wet cloth. If necessary, use a mild
cleaning agent.
Open the multi-purpose compartment.
Remove all items from the blank magazine.
Clean the blank magazine. Clean the clamping
levers very thoroughly.
Remove the cooling liquid tank.
Clean all surfaces in the multi-purpose com-
partment.
)
