R5 – Operation: Preparing jobs
F . 42 – P (
IG OSITIONING PINS LEFT MARKINGS
(
GROOVE IN THE SHAFT RIGHT MARKING
4.
Insert the shaft of the block into the desired pos-
ition in the block holder until it is firmly seated.
F . 43 – I
IG NSERTING A BLOCK INTO THE BLOCK HOLDER
;
SHOWN FROM BELOW GROOVE AND POSITIONING PIN MARKED
)
GREEN
5.
Use the provided torque wrench to fixate the
block with the corresponding fixing screw.
Tighten the screw firmly.
)
MUST LIE IN THE
)
(
HERE
Original Operating Instructions: R5
Version: 5/10/2019
F . 44 – S
IG CREWING DOWN THE SCREW TO IMMOBILIZE THE BLOCK
You can now mount the block holder.
F . 45 – A R5
IG N BLOCK HOLDER WITH
EN 37
5
MOUNTED BLOCKS
