8.
Thoroughly clean the blank holder from all sides
with a brush. Especially clean all openings and
movable parts of the blank holder.
9.
Allow the working chamber to dry.
10.
Install the protective strip in the working cham-
ber:
a.
Orient the protective strip so that the mag-
nets (marked orange) are on the right bot-
tom side.
F . 66 – C
IG ORRECT ORIENTATION OF THE PROTECTIVE STRIP
FOR INSTALLATION
b.
Align the right and the bottom edge of the
protective strip (colored green) with the
imaginary orange lines which are depicted
in the following illustration:
F . 67 – A
IG LIGNING THE PROTECTIVE STRIP
)
GREEN BEFORE INSTALLATION
c.
Push the protective strip to the right until it
snaps in place.
F
IG
ORANGE
11.
12.
Performing the weekly cleaning
1.
2.
3.
4.
5.
6.
7.
(
COLORED
Original Operating Instructions: R5
Version: 5/10/2019
R5 – Maintenance and do-it-yourself
. 68 – C
ORRECTLY INSTALLED PROTECTIVE STRIP
)
The protective strip is immobilized by the mag-
nets.
Close the working chamber door.
Move the spindle to the default pos-
ition by selecting the depicted icon in
Machining
the view in DentalCNC.
Have ready: The cleaning brush for the blank
holder.
Close the working chamber door.
Move the spindle to the cleaning pos-
ition by selecting the depicted icon in
Machining
the view in DentalCNC.
Open the working chamber door.
Remove the tool magazine from the working
chamber. Clean it with the cloth and the brush.
Clean the tool magazine holder with its respect-
ive brush.
Apply a bit of collet chuck grease to the bolts of
the tool magazine holder.
(
