R5 – Installing the machine
32.
Start DentalCNC.
DentalCNC establishes the connection to the
machine. The 2 check marks display again.
Although DentalCNC now establishes the
connection, SX Virtual Link is still required
for the connection to work.
33.
Continue with removing the transport lock from
the working chamber (see below).
Removing the transport lock
Before operating the machine for the first time, you
must remove the transport lock. The transport lock
prevents the spindle from getting damaged during
transport.
1.
Ensure the following:
The network connection to your machine
n
has been properly configured.
The machine is connected to the electrical
n
source.
The CAM computer is connected to your
n
machine.
2.
Switch on the machine at the main power switch.
The machine references.
3.
Start DentalCNC. Wait until the connection to the
machine has been established.
4.
Open the working chamber door by
selecting the depicted icon in the
Machining
view in DentalCNC.
5.
Open the blank holder by selecting the
depicted icon in the
DentalCNC.
6.
Remove the transport lock as shown in the sup-
plement.
Useful things to know about the
network configuration
Useful things to know about the
network configuration
While the network connection to your machine should
work automatically, there are some useful things that
you or your IT specialist should know.
What to do when devices are in use in SX
Virtual Link
If SX Virtual Link displays that 1 or more devices are in
use, another computer running SX Virtual Link has
taken control of them.
Machining
view in
Original Operating Instructions: R5
Version: 5/10/2019
F . 29 – D
IG EVICES THAT ARE IN USE BY OTHER COMPUTERS
1.
"In use" icon
2.
Name of the computer that is using the device
You can send a use request to the computer that is
currently connected to the device. If the request is
accepted, your computer can connect to the device.
1.
In the SX Virtual Link application window, right-
click on the corresponding device.
2.
From the context menu, select
The request displays in a pop up window on the
receiving computer. If the request is accepted,
your computer will connect to the device after a
short amount of time.
What to do if the machine is unreachable
If the network settings that are saved in the machine
are incorrect, your IT specialist may try the following to
connect to the machine:
1.
Access the router to which the machine is con-
nected.
2.
Determine the IP address of the machine via the
router's configuration menu.
3.
Configure the machine's network settings via the
web server (see below).
4.
If this is not possible, ask customer service to
reset the machine's network settings through
hardware access.
Network configuration via the machine's
web server
The machine features a web server which allows for
network configuration and network diagnostics.
You can access the web server as follows:
1.
Ensure that SX Virtual Link is connected to your
machine.
2.
In the SX Virtual Link application window, right-
click on the entry for the desired machine. If
required, use the Ethernet address to identify the
machine.
EN 29
Use request
.
