5 Installing the machine
Checking the scope of delivery
Unpack the machine and ensure that you have
received the following items:
1
3
7
11
15
2
4 5
8 9
12 13
Original Operating Instructions: R5
1.
1 x Machine R5
2.
1 x Spindle service set
3.
1 x Power cable
4.
1 x Ethernet network cable (type: straight)
5.
1 x Pneumatic hose
6.
1 x Torque wrench (1.8 Nm) (for mounting blocks)
7.
1 x Hex key (2.5 mm)
8.
1 x Crevice nozzle (for cleaning the working chamber)
9.
1 x Interdental brush (for cleaning the nozzle plate)
10.
1 x Cleaning brush
11.
1 x Drill bit (2.8 mm) for tool positions
12.
1 x Tool magazine insert
13.
1 x Calibration set: 1 micrometer, 6 blanks for man-
ufacturing test and calibration specimen
14.
1 x Measuring pin
15.
1 x Block holder
Not depicted:
This document
n
6
1 x Carrying aid for transporting the machine
n
1 x Transport lock in the working chamber
n
1 x Supplement about removing the carrying aid
n
and transport lock
Keep the packaging of the machine, the carrying
aid and the transport lock for future transports.
