EN 22
Installing the air extraction system
Components of the air extraction system:
Component Source
Suction Customer
device incl. service,
suction hose specialist
dealers
Switching Customer
unit service *
Data cable of Manufacturer
supported of the
suction units suction unit
Hose connec- Customer
tion service
The switching unit is not available worldwide.
*
Requirements for the suction unit
Use a suction device with the following properties
only:
Designed for the commercial use in the dental
n
sector
Equipped with a filter of the filter class M
n
Suitable for the operating site of the machine
n
Equipped with safety devices which protect you
n
from static discharges (e. g. through an anti-
static suction hose)
Minimum extraction capacity: 3,500 l/min at 220
n
hPa (123.6 cfm at 3.2 psi)
Required? Prerequisite
Yes –
No Suction unit
data cable not
used
No Supported
suction unit;
switching unit
not used
If the –
suction
hose does
not fit
Original Operating Instructions: R5
Version: 5/10/2019
R5 – Installing the machine
Installing the suction unit
You can install the suction unit as follows:
1.
Read the documentation for the suction unit. Fol-
low the operating and safety instructions at any
time.
2.
Check if the connection of the suction hose has
an outer diameter of 45 mm. If the diameter is dif-
ferent, either adjust the hose or use the optional
hose connection.
3.
Insert the suction hose of the suction unit into the
opening for the air extraction of the machine.
Ensure that the suction hose is properly seated.
F . 14 – I
IG NSERTING THE SUCTION HOSE INTO THE MACHINE
4.
If you want the machine to automatically switch
the suction unit on and off, choose 1 of the fol-
lowing options:
Install the switching unit (extra equipment).
n
The switching unit is not available world-
wide.
Connect a data cable provided by the manu-
n
facturer of the suction unit to the suction
unit data port of the machine. The oper-
ating manual of the suction unit should
contain additional details.
5.
Continue with the installation of the suction unit
as described in the documentation of the unit.
