VHF R5 Mode D'emploi D'origine page 45

R5 – Operation: Executing jobs
CAUTION
Danger of cuts and burns when
touching tools with your bare hands
If you handle tools on the cutting surface, you
may be injured. As the tool may be very hot, you
may also suffer from skin burns.
Only touch tools at their shank.
When handling tools, wear protective gloves.
5.
Hold the tool in the collet chuck in place.
6.
Confirm the current message.
The following happens:
a.
The collet chuck opens.
b.
The current dialog window closes.
c.
A dialog window opens.
7.
Remove the tool from the collet chuck.
F . 58 – R
IG EMOVING THE TOOL FROM THE COLLET CHUCK
8.
Close the working chamber door.
9.
Confirm the current message.
The following happens:
a.
The collet chuck closes.
b.
The working chamber door closes.
c.
The spindle moves to its default position.
DirectClean Technology
The DirectClean Technology of the R5 allows you to
process multiple jobs in succession using the blank
changer, even alternating between wet and dry jobs.
The machine will automatically rinse and / or dry the
working chamber.
The rinsing and drying process is triggered by the
sequence and type of jobs. You can find the corres-
ponding details in the table below.
If activated in the DentalCNC settings
1
Can be deactivated in the DentalCNC settings
2
D
You can also start the drying program manually.
Original Operating Instructions: R5
Version: 5/10/2019
Job followed by
Dry job no job Blowing off the
blank
Wet no job None
job
Dry job wet or dry job Blowing off the blank
Dry job no job Rinsing & drying
Wet dry job or no Drying
job job
Duration in minutes
Blank inserted into the working chamber
Blank(s) loaded from the blank magazine
It is a good idea to order the jobs in the job list
in DentalCNC in such a way that the cleaning
time is minimized. We recommend executing
all dry jobs followed by all wet jobs.
F . 59 – R
IG EORDERING JOBS IN THE JOB LIST IN
EN 45
Program D
1
1
–
1
2 17
15
D CNC
ENTAL
