Fig. 8: Fitting the adjustable articulated mounting 16-25 mm
6.3.3 Fitting the adjustable articulated mounting
32-80 mm
Fit the accessory to the shuttle with the screws supplied (M6)
and washers. Tightening torque 10 Nm.
Fig. 9: Fitting the adjustable articulated mounting 32-80 mm
55
Installation
00120554
00120555
