RT / RTx
Continued from the previous page.
■ Multiple rollers are not to be operated within 20 meters (65 feet) of one another,
unless you are certain you have each roller and its accompanying transmitter
set to a different control channel than the other rollers/transmitters being used
within the area.Refer to section Infra-red System and Control Channels for
additional information. Failure to assign different control channels can, in certain
circumstances, cause one transmitter to inadvertently take control of more than
one machine.
■ Always use the SmartControl™ SC-3 transmitter neck strap provided by Wacker
Neuson while operating with the control cable connected. This neck strap is
designed to break away so that the operator will not be dragged by the machine
should the machine slide, tip, or fall.
Stopping the
Perform the procedure below to stop the machine.
machine
1. Turn the vibration off by pressing the vibration off pushbutton (k).
2. Place the throttle switch (a) in the low speed (idle) position.
Note: The engine cannot be shut down using the throttle switch alone. The throttle
switch only changes the engine speed from high speed (fast) to low speed (idle).
3. Turn off the SmartControl™ SC-3 transmitter by pressing the red ON/OFF
pushbutton (g). The machine's engine will shut down.
4. Rotate the starting key (b) counterclockwise to the OFF (O) position.
Note: The machine has a built-in shutoff timer. If the starting key is left in the ON
position when the engine is not running, the timer will shut off the power to the
control panel after one hour.
A parking brake is located in the rear drum. The brake is connected to the hydraulic
system through the brake valve of the control manifold. The brake is spring
activated and hydraulically disengaged. Hydraulic oil flow to the brake is enabled
as soon as the engine starts. Thus, when the engine is running, the brake is
disengaged; when the engine is not running, the brake is engaged.
4.25
Emergency Shutdown Procedure
If a breakdown/accident occurs while the
machine is operating, follow the
procedure below.
1. Turn off the transmitter (a) to stop the
engine and close the fuel valve.
2. Turn the roller keyswitch to the OFF
position.
3. Return the machine to an upright
position if tipped over.
4. Contact rental yard or machine owner.
wc_tx003863gb_FM10.fm
67
Operation
a
wc_gr013391
