RT / RTx
14.8
Electrical Schematic Components—Kohler
Ref.
Description
Voltage regulator
4
L to ground when charging fault
5
Starter
6
Engine ground
7
Internal alternator
8
Relay—glow plugs
9
Relay—throttle pull
10
Relay—Power decoder
11
Fuse—decoder/display
12
Circuit breaker
33
Terminal ring
34
Engine glow plugs
BK
Black
GN
Green
BU
Blue
PK
Pink
wc_tx003865gb_FM10.fm
Wire Colors
RD
Red
YL
Yellow
OR
Orange
TN
Tan
BR
Brown
PU
Purple
VIO
Violet
CL
Clear
SH
Shield
WH
White
GY
Gray
LB
Lt. blue
157
Schematics
