4.13 Infra-red System and Control Channels
The infrared (IR) system consists of three main components: the SmartControl
SC-3 transmitter (a), the receiving eyes (b), and the decoder module (c).
The receiving eyes are positioned on the top of the machine enclosed within
protective lenses. They receive, filter and amplify the infrared transmission. They
include:
■ An integrated pre-amp to strengthen signal input
■ IR correction, to filter outside light interference
■ A frequency range of 500 kHz
There is an amber LED (d) on the base (bottom) of the front and rear receiving
eyes. When illuminated, the amber LED indicates:
■ Electric power is being supplied to the eye. The LED illuminates for the first 1–2
seconds after power has been applied (key switch is turned on).
■ The eye is receiving a signal from the SmartControl
The LED will remain on during operation.
The decoder module is positioned behind the hydraulic manifold at the back of the
machine. It receives, decodes, and outputs the signal from the transmitter module.
It is also the electric power supply for all hydraulic solenoids.
The IR system can be set to one of sixteen different control channels. Using
different channels allows multiple rollers to operate in the same area without
interference. Whenever multiple rollers are operated within 20 meters (65 feet) of
one another, make certain each roller and its accompanying transmitter is set to a
different control channel than the other rollers/transmitters being used within the
area.
Channel selection rotary switches (e and f) are included on both the transmitter
module and on the decoder module. The switches come from the factory set to the
last digit of the machine's serial number. For proper operation, BOTH switches
must be set to the SAME channel. The channel of each transmitter/machine pair is
identified by a label on both on the transmitter and the machine.
To change the control channel:
1. Remove the transmitter module battery and rotate the selector switch to the
desired position. Re-install the transmitter module battery.
2. Set the rotary switch on the decoder module to the same position as that of the
rotary switch on the transmitter module.
3. To determine if the decoder module and the transmitter module are set to the
same channel, turn the key switch to the ON position and set the transmitter
module's ON/OFF switch to the ON position. The amber lights on the machine's
light ring should blink at a slow rate indicating that the machine is receiving
signals from the transmitter module. If the amber lights illuminate but do not
blink, the transmitter module and the decoder module are not set to the same
channel.
4. Change the channel identification label to match the selected channel each time
the channel is changed. Channel identification labels are supplied with the
Operator's Manual.
