RT / RTx
14.14 Electrical Schematic Components—Kubota
Ref. Description
1 Receiving eye—middle
Signal
Ground (shield)
12 VDC
2 Diagnostic tool
3 Module—engine control module (ECM)
Power (in)
Power (out)
Light ring-red (out)
Start (in)
Fuel (in)
Throttle (in)
Sensor—oil pressure (in)
Sensor—water temperature-glow plugs (in)
Sensor—water temperature high (in)
Sensor—air filter (in)
Sensor—coolant level (in)
Ground
Light—low oil pressure (out)
Light—glow plugs (out)
Light—roll over (out)
Light—air filter (out)
Light—water temperature (out)
Light—coolant level (out)
Hour meter enable (out)
Solenoid—throttle pull (out)
Solenoid—throttle hold (out)
Solenoid—starter (out)
Glow plugs (out)
Solenoid—stop hold (out)
wc_tx003865gb_FM10.fm
Ref. Description
28 Receiving eye—front
Signal
Ground (shield)
12 VDC
29 Light ring—front
Lights—amber
Lights—red
Ground
(Not used)
30 Sensor—oil pressure
31 Sensor—air filter
32 Sensor—water temperature (glow plug thermistor)
33 Sensor—water temperature (high water temperature)
34 Snubber harness
35 Solenoid—throttle
BK Black RD
GN Green TN
BU Blue VIO
PK Pink WH
163
Schematics
Wire Colors
Red YL Yellow OR Orange
Tan BR Brown PU Purple
Violet CL Clear SH Shield
White GY Gray LB Lt. blue
