RT / RTx
14.18 Electrical Schematic Components—Kubota
Ref.
Description
4
Alternator with voltage regulator
5
Starter
6
Engine ground
7
Relay—glow plugs
8
Relay—throttle pull
9
50A fuse—glow plugs, throttle, and alternator
10
50A fuse—stop solenoid
11
Terminal ring
12
Engine glow plugs
13
Stop solenoid
14
Relay—power decoder
15
5A fuse—alternator
16
20A fuse—decoder/display
17
20A fuse—engine control module (ECM)
BK
Black
GN
Green
BU
Blue
PK
Pink
wc_tx003865gb_FM10.fm
Wire Colors
RD
Red
YL
Yellow
OR
Orange
TN
Tan
BR
Brown
PU
Purple
VIO
Violet
CL
Clear
SH
Shield
WH
White
GY
Gray
LB
Lt. blue
167
Schematics
