RT / RTx
14.22 Electrical Schematic Components — Compatec Compaction
Display (if equipped)
Ref.
Description
1
Fuse—decoder/display
2
Relay mini 50A
3
LED display
4
Sensor
5
Diagnostic port
6
Module—Compatec
Ground—battery minus (DG)
Ignition—battery plus (UB)
Power supply display (US-D)
Control line display (OC)
Signal ground display (SG3)
Power supply sensor (US1)
Input sensor (AE1)
Signal ground sensor (SG1)
RS232 interface (TxD)
RS232 interface (RxD)
RS232 signal ground (SG4)
BSL
7
Module—decoder
Ground
12 VDC output
8
Plug—trailer
Ground
12 VDC input
wc_tx003865gb_FM10.fm
BK
Black
RD
GN
Green
TN
BU
Blue
VIO
PK
Pink
WH
171
Schematics
Wire Colors
Red
YL
Yellow
OR
Orange
Tan
BR
Brown
PU
Purple
Violet
CL
Clear
SH
Shield
White
GY
Gray
LB
Lt. blue
