RT / RTx
14.12 Electrical Schematic Components—Kubota
Ref.
Description
1
Receiving eye—middle
2
Diagnostic tool
3
Module—engine control module (ECM)
4
Alternator with voltage regulator
5
Starter
6
Engine ground
7
Relay—glow plugs
8
Relay—throttle pull
9
50A fuse—glow plugs, throttle, and alternator
10
50A fuse—stop solenoid
11
Terminal ring
12
Engine glow plugs
13
Stop solenoid
14
Relay—power decoder
15
5A fuse—alternator
16
20A fuse—decoder/display
17
20A fuse—engine control module (ECM)
18
Battery
19
Charge port
20
Key switch
21
Throttle switch
22
Module—display
23
Module—decoder
24
Plug—trailer
25
Hydraulic valves
26
Receiving eye—rear
27
Light ring—rear
28
Receiving eye—front
29
Light ring—front
30
Sensor—oil pressure
31
Sensor—air filter
wc_tx003865gb_FM10.fm
Ref.
Description
32
Sensor—water temperature (glow plug thermistor)
33
Sensor—water temperature (high water temperature)
34
Snubber harness
35
Solenoid—throttle
BK
Black
RD
GN
Green
TN
BU
Blue
VIO
PK
Pink
WH
161
Schematics
Wire Colors
Red
YL
Yellow
OR
Orange
Tan
BR
Brown
PU
Purple
Violet
CL
Clear
SH
Shield
White
GY
Gray
LB
Lt. blue
