14.26 Hydraulic Schematic Components — 2
Ref. Description
1 Front exciter motor
2 Rear exciter motor
3 Exciter pump
4 Drive pump
5 Front drive motor
6 Rear drive motor
7 Drive front counterbalance valve
8 Drive rear counterbalance valve
9 Drive valve
10 Steering cylinder
11 Steering valve
12 Brake valve
13 Brake pressure reducing valve
wc_tx003865gb_FM10.fm
Ref. Description
14 High—speed travel valve
15 Exciter (vibration) high valve
16 Exciter (vibration) low valve
17 Exciter central relief valve
18 Exciter relief valve
19 Drive relief valve
20 Steering relief valve
21 Steering bypass valve
22 Return line filter
23 Oil cooler
24 Suction strainer
25 Control manifold
26 Parking brake
