RT / RTx
Ref
e
f
h
j
k
l
m
—
n
o
wc_tx003863gb_FM10.fm
Component
Near field transmitting
diodes (LEDs)
Operating status indicator
Engine START
pushbutton
ON/OFF pushbutton
LOW vibration pushbutton
Vibration OFF pushbutton
HIGH vibration
pushbutton
Vibration pushbuttons
Signal transmission
indicator
Control channel selector
switch
Description
These LEDs—located on all sides of the
transmitter—are part of the machine's sensing
system which stops the machine when the
operator and transmitter are located too close to
the machine.
This LED indicates the operating status of the
transmitter.
See Operating Status Indicator Codes.
Pressing this button causes the engine to crank.
An override prevents the engine from cranking if it
is already running.
Pressing this button turns on and off the
SmartControl™ transmitter. The operating status
indicator (f) illuminates green (flashing) when the
transmitter is on.
Turning the transmitter off stops the engine and the
machine. See topic 4.25 Emergency Shutdown
Procedure.
Pressing this button causes the vibration to come
on in the LOW vibration mode.
Pressing this button causes all vibration to stop.
Pressing this button causes the vibration to come
on in the HIGH vibration mode.
When the machine is moving in the high speed
travel mode, pressing either vibration pushbutton
(k or m) causes the roller to drop out of the high
speed travel mode and into the low speed travel
mode. Conversely, when the vibration is on, the
machine cannot go into the high speed travel
mode.
To aid in diagnostics, this green LED flashes any
time a signal is sent to the roller.
This selector switch, when set to match that of the
machine's decoder module, allows the
SmartControl to control the roller.
49
Operation
