RT / RTx
14.4 Electrical Schematic Components—Kohler
Ref. Description
1 Receiving eye—middle
Signal
Ground (shield)
12 VDC
2 Diagnostic tool
3 Module—engine control module (ECM)
Key switch (in)
Power on (out)
Light ring-red (out)
Start (in)
Fuel (in)
Throttle (in)
Sensor—-oil pressure (in)
Sensor—block temperature (in)
Sensor—water temperature (in)
Sensor—air filter (in)
Sensor—coolant level (in)
Ground
Light—low oil pressure (out)
Light—glow plugs (out)
Light—roll over (out)
Light—air filter (out)
Light—water temperature (out)
Light—coolant level (out)
Hour meter enable (out)
Throttle pull (out)
Throttle hold (out)
Solenoid—starter (out)
Glow plugs (out)
Fuel solenoid (out)
25 Sensor—temperature
wc_tx003865gb_FM10.fm
Ref. Description
Glow plugs
High temperature
26 Snubber harness
27 Solenoid—throttle
28 Solenoid—fuel energize to open
29 Receiving eye—front
Signal
Ground (shield)
12 VDC
30 Light ring—front
Lights—amber
Light—red
Ground
(Not used)
31 Sensor—oil pressure
32 Sensor—air filter
BK Black RD
GN Green TN
BU Blue VIO
PK Pink WH
153
Schematics
Wire Colors
Red YL Yellow OR Orange
Tan BR Brown PU Purple
Violet CL Clear SH Shield
White GY Gray LB Lt. blue
