5.8.1 Connecting Outflow Tube of Tissue Removal Handpiece (e.g.
MyoSure®)
(1) (2)
(1)
If intrauterine pathology is identified, the outflow tube of a tissue removal hand-
piece (6) is connected to the tissue trap (5) located in the second container.
(3) (4)
(7) (6)
(3) (6)
Fig. 5–10 Port for tissue removal sys-
tems
(1)
(5)
(2) Container
(3) Connecting tube
(4) Specimen tissue port
(5) Tissue trap
(6) Vacuum tube of tissue removal
(7) Tissue removal handpiece
System Operation
To high vacuum port (green)
handpiece (yellow)
