System Operation
EN
Figure 5-8 MyoSure®Connection
To High Vacuum port (green)
(1)
(2) Canisters
(3) Tandem tube
(4) Specimen tissue port
(5) Tissue trap
(6) MyoSure® vacuum tube
(7) MyoSure® Tissue Removal Device
(TRD)
20
Channel (MyoSure®) or hysteroscope outflow sheath.
5.8.1 MyoSure® Outflow Connection
(1)
(2)
(1)
If intrauterine pathology is identified, the MyoSure® TRD can be connected to the
Aquilex System as shown in Figure 5-8. The MyoSure® vacuum tube (6) is con-
nected to the tissue trap (5) located in the second canister.
(3)
(7)
(3)
(4)
(6)
(5)
(6)
