5.4 Turning On the Aquilex® System
1. Press the ON/OFF switch. The displays and indicators light up and system turns
on.
2. The system now performs a device self-test.
3. If a tube set is in the inflow tube holder when the pump is switched on, the
pump display (Fig. Front of irrigation pump unit [} 25] (1)) shows the message
Remove Tube Set. The device self-test resumes once the tube set is removed
from the roller wheel.
If the device self-test is unsuccessful, the corresponding error messages are
displayed (see Chapter Error and Warning Messages [} 54]).
The system has successfully completed the device self-test when a single audible
warning signal is heard. The message System OK is displayed for 5 seconds fol-
lowed by the message Insert Tube Set.
WARNING!
Obvious defects
Never use the system if it has suspected or confirmed defects, especially if these in-
volve the power plugs or the mains power supply connection cables. In this case
have the device repaired by authorized service personnel.
Fig. 5–6 High vacuum tube
(6) Hygiene filter
(7)
Vacuum tube (green connect-
ors)
(8) Connection for high vacuum
(green)
(9) Container
(10) Tissue trap (MyoSure® proced-
ures)
(12)
(11) Adjustment controller
(12) Connecting tube
(10)
(9)
Fig. 5–7 Front of Device
