Message in the pump display
Remove Tube Set for System Check 1 audible warning signal
Incorrect Tube Set
Pump Paused, Press Resume
Pressure Threshold
Press Prime Button
Service Menu
System Check Running
Calibration Running
Pump Operating
Maximum Pressure
Insert Tube Set
audible warning signals Method
Make sure all tube sets are removed from the roller wheel
during the system test. Remove tube set and wait until you
hear an audible warning signal and the message "Insert
Tube Set" appears.
Replace tube set. The tube set does not match the type ap-
1 audible warning signal
proved for the Aquilex® Fluid Control System .
Pause/Resume button has been activated. Press Pause/Re-
1 audible warning signal
sume button again to resume surgery.
For a hysteroscopy, pressures above 100 mmHg are usually
1 audible warning signal not necessary. Careful monitoring of the fluid deficit is re-
commended.
The system is waiting for user action to proceed. Please
1 audible warning signal
press Prime to start the lumen calibration.
The service menu is entered. Only relevant for service techni-
No audible warning signal cians, no user access allowed. Please refer to the service
manual for detailed information.
The system check is running. No user action required until
No audible warning signal
message "System OK" appears.
The system is proceeding the lumen calibration. No user ac-
No audible warning signal tion required until the message "Prime Successful Close
Stopcock" appears.
No audible warning signal The system is ready to use and operating as intended.
The message "Maximum Pressure" is depicted when the in-
No audible warning signal
trauterine pressure is greater than 150 mmHg.
The system is waiting for user action to proceed. Please in-
No audible warning signal
sert a valid tube set to operate the system as intended.
Error and Warning Messages
