MAINTENANCE

FIG. 42
FIG. 43
Note: Use only a genuine Evolution Riving Knife, as this is a
dedicated component for this machine. Non genuine parts could
be dangerous. If in any doubt, please contact the Helpline.
Push Stick
A plastic push stick is provided with the machine and has its
own dedicated storage brackets to the RH side of the machines
main body. (Fig. 42) When not in use store the push stick on
the machine.
Note: If the push stick becomes damaged it should be replaced. If the
operator makes their own push stick, we recommend that it follows
the same pattern as that supplied. Replacement push sticks are
available from Evolution Power Tools.
Blade Storage
A blade storage facility is available at the RH side of the
machine. (Fig. 43) Undo the centre hand nut and place any
spare blades onto the ø25.4mm metal flange. Secure the blades
with the centre hand nut.
