Fig. 11
To flush cut:
• Select and insert the correct saw blade into the machine.
• Position the side of saw blade directly against the floor, wall, etc.
• A side edge of the workpiece contact plate should be in
contact with the floor, wall, etc.
• Switch on the machine and gradually introduce the blade
into the workpiece.
• Adjust the stroke rate for optimum perfomance.
• Cut through the workpiece slowly allowing the flexible blade
to curve as required. (Fig. 11).
• Allow the side of the flexible blade to gently glide across the
floor, wall, etc.
CLEANING
WARNING: Any cleaning must only be attempted with the
machine disconnected from the mains power supply.
Clean the saw blade holder and remove any dirt and/or debris
build up. The saw blade should be removed from the machine
to facilitate proper and thorough cleaning.
Remove any contaminants by using a soft haired brush.
Compressed air can also be used. If this is the case the operator
should take all the necessary safety precautions to safeguard the
surrounding environment and any bystanders that may be present.
The operator should use all relevant PPE.
Safety glasses should be worn to protect the operators eyes
from blown debris.

MAINTENANCE

WARNING: Any maintenance must be carried out with the
machine switched off and disconnected from the mains/battery
power supply.
Check that all safety features and guards are operating correctly
on a regular basis. Only use this machine if all guards/safety
features are fully operational.
All motor bearings in this machine are lubricated for life. No further
lubrication is required.
Use a clean, slightly damp cloth to clean the plastic parts of the
machine. Do not use solvents or similar products which could
damage the plastic parts.
