9.3.1.2 Setting the customer menu - "Time" example
The setting of system-specific values is explained below using the setting of the
time as example.
To adjust the system-specific values, proceed as follows:
1. Press "Settings".
– The controller switches to the setting area.
2. Press "Customer >".
– The controller opens the Customer menu.
3. Press the required area.
– The controller switches to the selected area.
– Use the scroll bar to navigate through the list.
4. Set the system-specific values for the individual areas.
– Use the "Left" and "Right" buttons to select the display value.
– Use the "Up" and "Down" buttons to change the display value.
– Confirm your entries with "OK".
Press "i" to display a help text for the selected area.
Press "X" to cancel your input without saving the new settings. The controller
automatically opens again the list.
9.3.2 Service menu
This menu is protected with a password. It can be accessed only by the Reflex
Customer Service. A partial summary of the settings stored in the Service menu is
proved in the Chapter Default settings.
9.3.3 Default settings
The device controller is shipped with the following default settings. Use the
Customer menu to adjust these values to local conditions. In specific cases, it is
possible to further adjust the values in the Service menu.
Customer menu
Parameter
Language
Minimum operating
pressure P
0
Safety valve, pressure
Next maintenance
Volt-free contact
Make-up
Maximum make-up
quantity
Maximum make-up time
Maximum make-up
cycles
Degassing
Degassing programme
Continuous degassing
time
Softening (Only if "With
softening yes")
Lock make-up
Hardness reduction
Maximum make-up
quantity
Soft water capacity
Cartridge replacement
9.3.4 Degassing programmes – overview
You can choose between 2 degassing programs:
Continuous degassing
• Usage:
– For device commissioning.
– For degassing of the water after a device or facility system repair.
• Activation:
– An automatic activation occurs after completion of the start routine
during initial commissioning.
• Times:
– The time can be set in the Customer menu.
– The default setting is 24 hours. Subsequently, the system automatically
switches to Interval degassing.
In continuous degassing, the degassing cycles are sequentially performed for 24
hours.
Continuous degassing is pre-set in the customer menu as the default setting.
Interval degassing
• Usage:
– For continuous operation of the device.
• Activation:
– Automatic activation occurs after the ending of continuous degassing.
• Times:
– 8 degassing cycles per interval is set in the Service menu.
– After 8 intervals there is an idling time of 24 hours.
– The times for interval degassing are stored in the Service menu.
– Daily start of interval degassing is at 8:00 a.m.
 Note!
Manual activation of the degassing program takes place in the customer
menu.
Servimat M/L — 25.07.2024
Setting Remarks
EN Display language
1.5 bar Only Magcontrol
3.0 bar Pressure value for the safety
valve of the heat generator in the
system to trip
12 months Time left to the next due
maintenance
YES All messages from the Messages
list are displayed
0 Litres Only if controller with "With water
meter yes"
20 minutes Magcontrol
3 cycles within 2 Magcontrol
hours
Continuous
degassing
24 hours
No In the case of soft water residual
capacity = 0
8°dH = Target – Actual
0 Litres Attainable make-up quantity
0 Litres Attainable water capacity
18 months Replace cartridge
Controller
