500 mmHg using adjustment dial.
·
Use tandem tube ((12) Figure 5-5, High vacuum tube) when two canisters
are serially connected to the same vacuum port.
(6)
(7)
(8)
5.4

Turning On the Aquilex System

1. Press the ON/OFF switch. The displays and indicators light up and system
turns on.
2. The system now performs a self-diagnostic test.
3. If a tube set is in the inflow tube holder when the pump switches on, the
pump display (Fig. 5-1, Front of Pump (1)) shows Remove Tube Set. The self-
test resumes once the tube set is removed from the roller wheel.
If the system self-test is unsuccessful, the corresponding error messages are
displayed. (See Chapter 9, Error and Warning Messages).
The system has successfully completed the self-diagnostic test when a single au-
dible tone is heard. The message System OK is displayed for 5 secs followed by
the message Insert Tube Set.
WARNING!
Do not use this system if a defect is suspected or detected during the function
check. This also applies to any obvious defects, especially defects on the power
plug and power cord.
(11)
(12)
(10)
(9)
System Operation
Figure 5-5 High vacuum tube
Hygiene filter
(6)
Vacuum tube (green connectors)
(7)
High vacuum port (green)
(8)
Canisters
(9)
(10) Tissue trap (MyoSure® procedures)
Adjustment dial
(11)
Tandem tube
(12)
