Section 2
Clearance Requirements
,
The ice machine must be protected if it
will be subjected to temperatures below
32°F (0°C). Failure caused by exposure to
freezing temperatures is not covered by
the warranty.
Head Sections
Model
Top/Sides
ST3000W
SF3000C
(20 cm)
Condensing Unit
Model
Top/Sides
CVDF3000
(15 cm)
NOTE: 24" on all sides is recommended to allow
access for maintenance and service.
Ice Machine Heat of Rejection
Model
Conditioning
ST3000W
BTU/Hour
Use this information when:
• Sizing air conditioning equipment where
self‑contained ice machines are installed.
• Determining the load on a cooling tower.
Use the peak figure for sizing the load.
Part Number 000017556 Rev 00 9/22
Caution
Back
8"
24"
(61 cm)
Front/Back
6"
24"
(61 cm)
Heat of Rejection
Air
Peak
45,000
51,000
Bin Installation
1.
Remove threaded plug from drain
fitting.
2.
Screw the leveling legs onto the
bottom of the bin.
3.
Screw the foot of each leg in as far as
possible.
4.
Move the bin into its final position.
5.
Level the bin to assure that the bin
door closes and seals properly. Use a
level on top of the bin. Turn the base
of each foot as necessary to level the
bin.
6.
Inspect bin gasket prior to ice machine
installation. Manitowoc bins come
with a closed cell foam gasket installed
along the top surface of the bin.
n
Remove all panels from ice machine before
lifting and installing on bin. Remove front
panel, top cover, left and right side panels.
Installation
Warning
15
