Commissioning; Before Switching On - Lenze 8200 Vector Instructions De Montage

7

Commissioning

Before switching on

)
Note!
Do not change the switch−on sequence.
l
In the event of an error during commissioning, please see the chapter "Fault
l
detection and elimination".
To avoid injury to persons or damage to property, check...
... before the mains voltage is connected:
The wiring for completeness, short circuit and earth fault
l
"Emergency−off" function of the whole system
l
Motor connection (star/delta) must be adapted to output voltage of controller.
l
If you do not use a function module, ensure that the FIF cover is mounted properly
l
(as delivered).
If the internal voltage supply X3/20 of e.g. the standard I/O is used, the terminals
l
X3/7 and X3/39 must be jumpered.
... the most important drive parameter settings before the controller is enabled:
Are the drive parameters relevant for your application set correctly?
l
– E.g. configuration of analog and digital inputs and outputs
114
