Using the keypad XT EMZ9371BC − Parameter setting
1
Adoption of parameters
Display Meaning
p
Parameters are adopted immediately
p
SHPRG Parameter must be confirmed with
SHPRG In case of controller inhibit the parameter must be
confirmed with
none Display parameter
2
Active level
Display Meaning
Menu Menu level active
Code Code level active
Para Parameter level active
none Operation level active
3
Short text
Display Meaning
max. 13 characters Contents of menus, meaning of codes and
parameters
In operation level display of C0004 in % and active
fault
4
Number
Active level Meaning
Menu level Menu number
Code level four−digit code number
5
Number
Active level Meaning
Menu level Submenu number
Code level two−digit subcode number
6
Parameter value
Parameter value with unit
7
Cursor
In the parameter level the number above the cursor can be directly changed
8
Function keys
For description see the following table
L
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Explanation
Basic device operates immediately with the new
parameter value
T V
Basic device operates with the new parameter
value, after it was confirmed
Basic device operates with the new parameter
T V
value, after the controller has been enabled
Change not possible
Explanation
Select main menu and submenus
Select codes and subcodes
Change parameters in the codes or subcodes
Display operation parameters:
l
l
l
Explanation
Explanation
Display only active when operating with the basic
device series 8200 vector or 8200 motec
Explanation
Display only active when operating with the basic
device series 8200 vector or 8200 motec
EDK82EV113 DE/EN/FR 8.1
7
Commissioning
User menu, memory location 1 (C0517/1)
Status display C0004 in %
Active fault
