Error messages at the keypad or in the parameter setting program Global Drive
Control
1)
Keypad PC Error
0 No fault
noer
71 System fault
ccr
a
61 Communication fault to
ce0
a AIF
(configurable in C0126)
62 Communication fault to
ce1
a
CAN−IN1 with Sync
control
63 Communication error to
ce2
a CAN−IN2
64 Communication error to
ce3
a CAN−IN1 with event or
time control
65 BUS−OFF
ce4
a
(many communication
faults occurred)
66 CAN Time−Out
ce5
a
(configurable in C0126)
67 Function module
ce6
a
system bus (CAN) on
FIF has set "Warning"
or "BUS−OFF"
(configurable in C0126)
L
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Fault detection and elimination
Cause Remedy
− −
Strong interferences on control cables Shield control cables
Ground or earth loops in the wiring
Faulty transmission of control Insert the communication module into the
commands via AIF hand terminal
CAN−IN1 object receives faulty data or
l
communication is interrupted
l
l
CAN−IN2 object receives faulty data or
l
communication is interrupted
l
l
CAN−IN1 object receives faulty data or
l
communication is interrupted
l
l
Controller has received too many
l
incorrect telegrams via the system
l
bus and has been disconnected
l
l
For remote parameter setting via
l
system bus (C0370):
l
Slave does not answer.
Communication monitoring time
exceeded.
For operation with module in FIF: Contact Lenze
Internal fault
CAN controller sets "Warning" or "BUS l
OFF"
l
l
l
EDK82EV113 DE/EN/FR 8.1
8
Fault messages
ó
Plug−in connection − bus module
Check FIF
Check transmitter
Increase monitoring time under C0357/1
if necessary
ó
Plug−in connection − bus module
Check FIF
Check transmitter
Increase monitoring time under C0357/2
if necessary
ó
Plug−in connection − bus module
Check FIF
Check transmitter
Increase monitoring time under C0357/3
if necessary
Check whether bus terminator available
Check screen contact of the cables
Check PE connection
Check bus load, if necessary, reduce the
baud rate
Check system bus wiring
Check system bus configuration
Check whether bus terminator available
Check screen contact of the cables
Check PE connection
Check bus load, if necessary, reduce the
baud rate
