Commissioning
Using the keypad XT EMZ9371BC − Parameter setting

Menu structure

Main menu Submenus
No. Display No. Display
1 USER menu
2 Code list
2.1 ALL
2.2 Para set 1
2.3 Para set 2
2.4 Para set 3
2.5 Para set 4
3 Remote para See description of the keypad Remote parameter setting
4 Quick start
4.1 Keypad quick
4.2 V/f quick
4.3 VectorCtrl qu
5 Short setup See description of the keypad Quick configuration of predefined applications
6 Diagnostic
6.1 Fault history
6.2 Status words
6.3 Monit drive
6.4 Monit FIF
7 Param managm
7.1 Load/Store
7.2 Copy PAR1 −>2
7.3 Copy PAR1 −>3
7.4 Copy PAR1 −>4
132
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Description
Defined codes in C0517
All available codes
All available codes in ascending order (C0001 ... C7999)
Codes in parameter set 1 (C0001 ... C1999)
Codes in parameter set 2 (C2001 ... C3999)
Codes in parameter set 3 (C4001 ... C5999)
Codes in parameter set 4 (C6001 ... C7999)
Only active with function module system bus (CAN)
Quick commissioning of standard applications
Function check
Linear V/f−characteristic control
Frequency setpoint via keypad
Linear V/f−characteristic control
Frequency setpoint selectable analogically via potentiometer, fixed
setpoints (JOG) selectable via terminal
Vector control
Frequency setpoint selectable analogically via potentiometer, fixed
setpoints (JOG) selectable via terminal
Diagnostics
Error analysis with history buffer
Display of status words
Display codes in order to monitor drive
Display codes in order to monitor a field bus function module
Parameter set management
Parameter set transfer, restore delivery status
Copy parameter set 1 into parameter set 2
Copy parameter set 1 into parameter set 3
Copy parameter set 1 into parameter set 4
