The menu user − The 10 most important drive parameters
After mains switching or plugging in the keypad during operation, the 10 codes defined in
code C0517 are immediately available.
In default setting the menu user contains all codes required for a standard application with
linear V/f characteristic control.
Code Name
C0050 Output frequency
C0034 Setpoint selection range
C0007 Fixed configuration of digital inputs
C0010 Minimum output frequency
C0011 Maximum output frequency
C0012 Acceleration time main setpoint
C0013 Deceleration time main setpoint
C0015 V/f rated frequency
C0016 V boost
min
C0002 Parameter set management
)
Note!
Use C0002 "Parameter set transfer/restorage of default setting" to transfer
configurations from one controller to the other with keypad or restore the
default setting by loading the Lenze setting (e.g. if you lost track during
parameter setting).
L
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Using the keypad E82ZBC − Parameter setting
Lenze setting
Display: Output frequency without slip compensation
0 Standard I/O X3/8:
X3/1U:
Application I/O
X3/2U:
0 E4
CW/CCW DCB
CW/CCW rotation DC injection
brake
0.00 Hz
50.00 Hz
5.00 sec
5.00 sec
50.00 Hz
Depending on the controller
Restore default setting; Transfer parameter sets with keypad; save, load
or copy own basic settings
EDK82EV113 DE/EN/FR 8.1
7
Commissioning
0 ... 5 V / 0 ... 10 V / 0 ... 20 mA
0 ... 5 V / 0 ... 10 V
0 ... 5 V / 0 ... 10 V
E3 E2 E1
JOG2/3 JOG1/3
Selection of fixed setpoints
