Technical data

Operation with increased rated power

Under the application conditions described here the controller can be operated in
continuous operation with a motor of higher performance. The overload capacity is
reduced to 120 %.
Typical applications are pumps with square−law load characteristic or blowers.
)
Note!
Operation with increased rated power is only permissible
with the drive controllers mentioned
l
within the mains voltage range mentioned
l
with the chopper frequency mentioned
l
with the prescribed fuses, cable cross−sections and mains chokes
l
Type Rated mains voltage
Power
[kW]
E82EV302K2C 3.0
3/PE AC 230/240 V
E82EV402K2C 4.0
E82EV552K2C 5.5
E82EV752K2C 7.5
E82EV302K4C 3.0
E82EV402K4C 4.0
E82EV552K4C 5.5
E82EV752K4C 7.5
E82EV113K4C 11.0

without mains choke
‚
With mains choke
1)
For rated mains voltage and chopper frequency 2 kHz or 4 kHz
2)
Currents for periodic load change: 1 min overcurrent with I
94
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Mains current [A]

18.7
50 Hz
−
DC 325 V
10.8
−
3/PE AC 400 V
50 Hz
DC 565 V
−
and 2 min basic load with 75 % I
max
EDK82EV113 DE/EN/FR 8.1
1)
Output current [A]
‚
2)
I I (60 s)
r max
14.4 14.4 18.0
Operation not possible
25,7 27 33.8
Operation not possible
8.4 8.7 11.0
10.6 11.4 14.2
Operation not possible
18.0 19.8 24.8
Operation not possible
rx
