42 AVENTICS | RCM | R499050098–BDL–001–AD

Device description

1
10
Fig. 1: Overview of the RCM rotary compact module (design with integrated intermediate position,
integrated air ducts, and elastic cushioning element)
1 Intermediate position system (IP)
2 Base
3 Threaded/through holes with
countersinking to fasten the RCM rotary
compact module
4 Threaded holes with countersinking
tofasten useful loads
5 Rotary flange
4 Device description
2 3
9
4 5
8
6 End cover
7 End position system (with angle
adjustment and cushioning)
– Elastic cushioning (SE)
– Hydraulic cushioning (SH)
8 Air ducts (AP)
9 Sensor grooves
10 Compressed air connections
6 7
