48 AVENTICS | RCM | R499050098–BDL–001–AD
Assembly
5.1.6

Fastening useful loads on the rotary flange

Fasten the useful load on the rotary flange with at least two
O
screws and centering sleeves (see Fig. 8).
Protruding screws
Screws protruding from the bottom of the rotary flange will
block the rotary movement and damage the RCM rotary
compact module.
Only use screws with the suitable length.
O
1
2
Fig. 8: Fastening the useful load on the rotary flange
1 Mounting screw
2 Centering sleeve
NOTICE
M
A
