AVENTICS | RCM | R499050098–BDL–001–AD
5.1.4

Fastening variant from above

Fig. 6: Fastening from above with through holes
1 Mounting screw
2 Centering sleeve
5.1.5

Fastening variant from below

RCM-06/-12
2 1
M
A
Fig. 7: Fastening from below with threaded holes
1 Mounting screw
2 Centering sleeve
Table 3: Thread depth T and tightening torque M
RCM-06
(M4)
+0,5
T [mm] 7
0,3
M [Nm] 3
A
2 1
RCM-08/-16/-20/-25
2 1
RCM-08 RCM-12
(M5) (M5)
+0,5 +0,5
9,1 8,5
0,6 0,6
6 6
47
Assembly
M
A
A
RCM-20
RCM-16
RCM-25
(M6) (M8)
+0,5 +1
11,1 14,1
1 2,5
10 25
