58 AVENTICS | RCM | R499050098–BDL–001–AD
Commissioning
_
3
L
min.
5
Fig. 17: Adjusting the intermediate position 90° – 110°
5. Adjust the intermediate position bolt (3) to the desired
intermediate position.
6. Fasten the intermediate position bolt (3) and retighten the
lock nut (2).
7. Screw the intermediate position bolt (5) back in until no
angle play can be felt by hand at the rotary flange.
Screwing the intermediate position bolt in too far will result
in multiple intermediate positions.
8. Fasten the intermediate position bolt (5) and retighten the
lock nut (4).
9. Check the intermediate position.
+
2
B
C
A
4
L
min.
Table 8:
2/4
3/5
1)
Hexagon socket
90
1
p
Wrench size SW, tightening torques M
screw L
min.
RCM-12
SW
M [Nm]
A
1)
SW
L [mm]
min.
110
A
RCM-16 RCM-20
7 7
2,5 2,5
2 2
5 5
and reach of
RCM-25
8 10
4 8
2,5 3
6 7
