Rated data

Operation with rated power (normal operation)

For data for operation at rated mains voltage and switching frequency 8 kHz, sin. data and restrictions
for other switching frequencys see system manual.
Type
Power
[kW]
P
E82xV302K2C
3.0
E82xV402K2C
4.0
E82xV552K2C
5.5
2)
E82xV752K2C
7.5
E82xV302K4C
3.0
E82xV402K4C
4.0
E82xV552K4C
5.5
E82xV752K4C
7.5
2)
E82xV113K4C
11
E82xV302K4C
3.0
E82xV402K4C
4.0
E82xV552K4C
5.5
E82xV752K4C
7.5
2)
E82xV113K4C
11
1)
Currents for periodic load change: 1 min overcurrent time with I
2)
Operation only permitted with mains choke (
Operation with increased rated power
,
System Manual
EDK82EV113 DE/EN/FR 11.0
Operation with rated power (normal operation)
Rated mains voltage
r
3/PE AC 230/240 V:
180 V −0 % ... 264 V +0 %
45 Hz −0 % ... 65 Hz +0 %
DC 325 V:
260 V −0 % ... 370 V +0 %
3/PE AC 400 V:
320 V −0 % ... 440 V +0 %
45 Hz −0 % ... 65 Hz +0 %
DC 565 V:
450 V −0 % ... 620 V +0 %
3/PE AC 500 V:
400 V −0 % ... 550 V +0 %
45 Hz −0 % ... 65 Hz +0 %
DC 710 V:
565 V −0 % ... 775 V +0 %
^
Mains current [A]
without
with
mains choke
15.6
12.0
21.3
16.0
29.3
21.0
28.0
9.0
7.0
12.3
8.8
16.8
12.0
21.5
15.0
21.0
7.2
5.6
9.8
7.0
13.4
9.6
17.2
12.0
16.8
and 2 min base load time with 75 % I
max
117)
l
Technical data
Rated data
Output current [A] )
I
r
I
(60 s)
max
1)
12.0
18.0
16.5
24.8
(E82CV... 2.4)
22.5
33.8
(E82CV... 3.0)
28.6
42.9
7.3
11.0
9.5
14.2
(E82CV... 2.4)
13.0
19.5
16.5
24.8
(E82CV... 3.0)
23.5
35.3
5.8
11.0
7.6
14.2
(E82CV... 2.4)
10.4
19.5
13.2
24.8
(E82CV... 3.0)
18.8
35.3
3
Mass
[kg]
2.9
3.6
2.9
3.6
2.9
3.6
r
103
