Technical Data
Electrical data
Power
Rated current
Rated voltage
Mains connection
Power supply frequency
Overvoltage category (IEC 60664)
Integrated residual current device
Protection class
Degree of protection
Vehicle plug
Mechanical data
Weight of control unit with cable
Vehicle cable length
Supply cable length
Ambient and storage conditions
Ambient temperature
1. The x stands for future design changes and is replaced by the letters A to W.
PMCPU96x
1
9.6 kW
40 A, 1-phase
120/208 – 240 V
L, N, PE
50 Hz/60 Hz
II
Type A (AC: 20 mA) +DC: 56 mA
I
IP55 (USA: Enclosure 3R)
Type 1
7.5 lbs (3.4 kg)
14.8 ft (4.5 m)
US/JET type 1 ft. (0.3 m)
–22 °F – +122 °F (-30 °C – +50 °C)
Technical Data
