SICK TiM781 Notice D'instruction page 105

Table 141 : Example: sRA ODpwrc
<STX>sRA{SPC}ODpwrc{SPC}752D<ETX>
CoLa A
02 73 52 41 20 4F 44 70 77 72 63
CoLa B 02 02 02 02 00 00 00 0F
12.3.1.4.6.7
With this command the internal temperature of the device can be identified. Please note that it does not give an
indication of the current ambient temperature.
Table 142 : Telegram structure: sRN OPcurtmpdev
Telegram structure: sRN OPcurtmpdev
Telegram Description
part
Command Read
type
Command Read temperature of
the device
Table 143 : Example: sRN OPcurtmpdev
<STX>sRN{SPC}OPcurtmpdev<ETX>
<STX>sRN OPcurtmpdev<ETX>
CoLa A
sRN OPcurtmpdev
02 73 52 4E 20 4F 50 63 75 72 74 6D 70 64 65 76 03
02 02 02 02 00 00 00 0F
CoLa B
73 52 4E 20 4F 50 63 75 72 74 6D 70 64 65 76
Table 144 : Telegram structure: sRA OPcurtmpdev
Telegram structure: sRA OPcurtmpdev
Telegram Description
part
Command Answer
type
Command Read temperature of
the device
Tempera‐ [°C]
ture data
Example: sRA OPcurtmpdev (35°C)
Table 145 : Example: sRA OPcurtmpdev
<STX>sRA{SPC}OPcurtmpdev{SPC}420C0000<ETX>
CoLa A
02 73 52 41 20 4F 50 63 75 72 74 6D 70 64 65 76
CoLa B 02 02 02 02 00 00 00 14
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
20 752D 03
73 52 41 20 4F 44 70 77 72 63
Read temperature [sRN OPcurtmpdev]
Variable Length
String 3
String 11
73 52 4E 20 4F 50 63 75 72 74 6D 70 64 65 76
Variable Length
String 3
String 11
Real as 4
float
according
to
IEEE754
73 52 41 20 4F 50 63 75 72 74 6D 70 64 65 76
20 00 00 75 2D 36
Additional details
2A
Additional details
(-50°C ... +100°C)
20 34 32 30 43 30 30 30 30
20
ANNEXE
Values CoLa A Values CoLa B
(ASCII) (Binary)
sRN 73 52 4E
OPcurtmpdev 4F 50 63 75 72
74 6D 70 64
65 76
Values CoLa A Values CoLa B
(ASCII) (Binary)
sRA 73 52 41
OPcurtmpdev 4F 50 63 75 72
74 6D 70 64
65 76
C2480000h ... C2 48 00 00
42C80000h 42 C8 00 00
03
42 0C 00 00 4B
