Table 50 : Example: sMN Run
<STX>sMN{SPC}Run<ETX>
<STX>sMN Run<ETX>
CoLa A
sMN Run
02 73 4D 4E 20 52 75 6E 03
02 02 02 02 00 00 00 07
CoLa B
73 4D 4E 20 52 75 6E
Table 51 : Telegram structure: sAN Run
Telegram Description
part
Command Answer
type
Command Start the device
Status Accepted when value is
code 1
Table 52 : Example: sAN Run
<STX>sAN{SPC}Run{SPC}1<ETX>
CoLa A
02 73 41 4E 20 52 75 6E
CoLa B 02 02 02 02 00 00 00 09
12.3.1.4.2.8
This command includes saving all parameters.
Table 53 : Telegram structure: sMN mSCreboot
Telegram structure: sMN mSCreboot
Telegram Description
part
Command Method
type
Command Reboot device
Table 54 : Example: sMN mSCreboot
<STX>sMN{SPC}mSCreboot<ETX>
<STX>sMN mSCreboot<ETX>
CoLa A
sMN mSCreboot
02 73 4D 4E 20 6D 53 43 72 65 62 6F 6F 74 03
02 02 02 02 00 00 00 0D
CoLa B
73 4D 4E 20 6D 53 43 72 65 62 6F 6F 74
76 N O T I C E D ' I N S T R U C T I O N | TiM781
73 4D 4E 20 52 75 6E
Telegram structure: sAN Run
Variable Length
String 3
String 3
Bool_1 1
20 31 03
73 41 4E 20 52 75 6E
Reboot device [sMN mSCreboot]
(User level 'Service' required)
Variable Length
String 3
String 9
73 4D 4E 20 6D 53 43 72 65 62 6F 6F 74
19
Additional details
Error:
Success:
20 01 34
Additional details
2C
Values CoLa A Values CoLa B
(ASCII) (Binary)
sAN 73 41 4E
Run 52 75 6E
0 00
1 01
Values CoLa A Values CoLa B
(ASCII) (Binary)
sMN 73 4D 4E
mSCreboot 6D 53 43 72
65 62 6F 6F 74
