SICK TiM781 Notice D'instruction page 116

12
ANNEXE
Table 187 : Example for TiM781: Example: sWN FieldSetSelectionMethod
<STX>sWN{SPC}FieldSetSelectionMethod{SPC}1<ETX>
<STX>sWN FieldSetSelectionMethod 1<ETX>
CoLa A
sWN FieldSetSelectionMethod 1
02 73 57 4E 20 46 69 65 6C 64 53 65 74 53 65 6C 65 63 74 69 6F 6E 4D 65 74 68 6F 64 20 31 03
02 02 02 02 00 00 00 13
64 20 01 14
CoLa B
73 57 4E 20 46 69 65 6C 64 53 65 74 53 65 6C 65 63 74 69 6F 6E 4D 65 74 68 6F 64 20 01
Table 188 : Telegram structure: sWA FieldSetSelectionMethod
Telegram structure: sWA FieldSetSelectionMethod
Telegram Description
part
Command Answer
type
Command Fieldset selection
Method
Table 189 : Example: sWA FieldSetSelectionMethod
<STX>sWA{SPC}FieldSetSelectionMethod<ETX>
CoLa A
02 73 57 41 20 46 69 65 6C 64 53 65 74 53 65 6C 65 63 74 69 6F 6E 4D 65 74 68 6F 64
02 02 02 02 00 00 00 15
CoLa B
64 20 1A
12.3.1.4.8.2
Read if the device will switch from one to another defined fieldset via a pre-defined status change of the digital
inputs or via a telegram command.
Table 190 : Telegram structure: sRN FieldSetSelectionMethod
Telegram structure: sRN FieldSetSelectionMethod
Telegram Description
part
Command Read
type
Command Fieldset selection
Method
Table 191 : Example: sRN FieldSetSelectionMethod
<STX>sRN{SPC}FieldSetSelectionMethod<ETX>
<STX>sRN FieldSetSelectionMethod<ETX>
CoLa A
sRN FieldSetSelectionMethod
02 73 52 4E 20 46 69 65 6C 64 53 65 74 53 65 6C 65 63 74 69 6F 6E 4D 65 74 68 6F 64 03
116 N O T I C E D ' I N S T R U C T I O N | TiM781
73 57 4E 20 46 69 65 6C 64 53 65 74 53 65 6C 65 63 74 69 6F 6E 4D 65 74 68 6F
Variable Length
String 3
String 23
73 52 41 20 46 69 65 6C 64 53 65 74 53 65 6C 65 63 74 69 6F 6E 4D 65 74 68 6F
Read Fieldset selection method [sRN FieldSetSelectionMethod]
Variable Length
String 3
String 23
Additional details Values CoLa A
sWA
FieldSetSelec‐
tionMethod
Additional details Values CoLa A
sRN
FieldSetSelec‐
tionMethod
Values CoLa B
(ASCII) (Binary)
73 57 41
46 69 65 6C
64 53 65 74
53 65 6C 65
63 74 69 6F 6E
4D 65 74 68
6F 64
03
Values CoLa B
(ASCII) (Binary)
73 52 4E
46 69 65 6C
64 53 65 74
53 65 6C 65
63 74 69 6F 6E
4D 65 74 68
6F 64
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
