Table 45 : Telegram structure: sMN mEEwriteall
Telegram structure: sMN mEEwriteall
(User level 'Authorized client' required)
Telegram Description
part
Command Method
type
Command Store parameters per‐
manently
Table 46 : Example: sMN mEEwriteall
<STX>sMN{SPC}mEEwriteall<ETX>
<STX>sMN mEEwriteall<ETX>
CoLa A
sMN mEEwriteall
02 73 4D 4E 20 6D 45 45 77 72 69 74 65 61 6C 6C
02 02 02 02 00 00 00 0F
CoLa B
73 4D 4E 20 6D 45 45 77 72 69 74 65 61 6C 6C
Table 47 : Telegram structure: sAN mEEwriteall
Telegram structure: sAN mEEwriteall
Telegram Description
part
Command Answer
type
Command Store parameters per‐
manently
Status Accepted when value is
code 1
Table 48 : Example: sAN mEEwriteall
<STX>sAN{SPC}mEEwriteall{SPC}1<ETX>
CoLa A
02 73 41 4E 20 6D 45 45 77 72 69 74 65 61 6C 6C
CoLa B 02 02 02 02 00 00 00 11
12.3.1.4.2.7
Log out from device and activate all parameter changes.
Table 49 : Telegram structure: sMN Run
Telegram Description
part
Command Method
type
Command Start the device
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
Variable Length
String 3
String 11
73 4D 4E 20 6D 45 45 77 72 69 74 65 61 6C 6C
Variable Length
String 3
String 11
Bool_1 1
73 41 4E 20 6D 45 45 77 72 69 74 65 61 6C 6C
Set to run [sMN Run]
Telegram structure: sMN Run
Variable Length
String 3
String 3
Additional details
03
21
Additional details
Error:
Success:
20 31 03
20
Additional details
ANNEXE
Values CoLa A Values CoLa B
(ASCII) (Binary)
sMN 73 4D 4E
mEEwriteall 6D 45 45 77
72 69 74 65
61 6C 6C
Values CoLa A Values CoLa B
(ASCII) (Binary)
sAN 73 41 4E
mEEwriteall 6D 45 45 77
72 69 74 65
61 6C 6C
0 00
1 01
01 0C
Values CoLa A Values CoLa B
(ASCII) (Binary)
sMN 73 4D 4E
Run 52 75 6E
