SICK TiM781 Notice D'instruction page 103

Table 131 : Example: sRN DItype
<STX>sRN{SPC}DItype<ETX>
<STX>sRN DItype<ETX>
CoLa A
sRN DItype
02 73 52 4E 20 44 49 74 79 70 65 03
02 02 02 02 00 00 00 0A
CoLa B
73 52 4E 20 44 49 74 79 70 65
Table 132 : Telegram structure: sRA DItype
Telegram Description
part
Command Answer
type
Command Ask state
Length of Number of digits of
type key the following type code
length
Device Type code of the device String
type
Table 133 : sRA DItype Example for TiM561-2050101:
<STX>sRA{SPC}DItype{SPC}E{SPC}TIM561-2050101<ETX>
CoLa A
02 73 52 41 20 44 49 74 79 70 65
02 02 02 02 00 00 00 1A
CoLa B
03
12.3.1.4.6.5
Table 134 : Telegram structure: sRN ODoprh
Telegram Description
part
Command Read
type
Command Read operating hours
Table 135 : Example: sRN ODoprh
<STX>sRN{SPC}ODoprh<ETX>
<STX>sRN ODoprh<ETX>
CoLa A
sRN ODoprh
02 73 52 4E 20 4F 44 6F 70 72 68 03
02 02 02 02 00 00 00 0A
CoLa B
73 52 4E 20 4F 44 6F 70 72 68
8024232/1ONO/2024-09-25 | SICK
Subject to change without notice
73 52 4E 20 44 49 74 79 70 65
Telegram structure: sRA DItype
Variable Length
String 3
String 6
Uint_8 1
(var.)
20 45 20 54 49 4D 35 36 31 2D 32 30 35 30 31 30 31
73 52 41 20 44 49 74 79 70 65
Read operating hours [sRN ODoprh]
Telegram structure: sRN ODoprh
Variable Length
String 3
String 6
73 52 4E 20 4F 44 6F 70 72 68
5A
Additional details Values CoLa A
sRA
DItype
0d ... 255d (0h
... FFh)
(Device type)
20 0E 54 49 4D 35 36 31 2D 32 30 35 30 31 30 31
Additional details Values CoLa A
sRN
ODoprh
41
N O T I C E D ' I N S T R U C T I O N | TiM781
12
ANNEXE
Values CoLa B
(ASCII) (Binary)
73 52 41
44 49 74 79
70 65
00 ... FF
(Device type)
03
Values CoLa B
(ASCII) (Binary)
73 52 4E
4F 44 6F 70 72
68
103
