Level 2: AC / polarity reversal set-up parameters

Select "Parameter -
2nd"
-
-
Important! The first parameter to be displayed is always the one that was the last to be
selected the last time the set-up menu was accessed.
-
Accessing Once the set-up parameter "2nd" has been selected:
-
-
Important! The first parameter to be displayed is always the one that was the last to be
selected the last time the set-up menu was accessed.
Selecting and -
altering the set-
up parameter -
Exiting and -
saving
Available set-up PoS .... positive ... positive half-wave ... tri / Sin / rEc / OFF, factory setting: Sin
parameters
nEG .... negative ... negative half-wave tri / Sin / rEc / OFF, factory setting: rEc
Press the "Process" button (6) to select the AC welding process
(6)
While pressing and holding the Store button (13), press the "Process" button (6)
The first set-up parameter is displayed (e.g. "ACF")
Select the set-up parameter "2nd" with the parameter selection buttons (8) and (9).
While pressing and holding the Store button (13), press the "Process" button (6)
The first set-up parameter of Level 2 is displayed (e.g. "PoS")
Select the desired set-up parameter with the parameter selection buttons (8) and
(9).
Alter the value of the set-up parameter with the adjusting dial (7)
Press the Store button (13) twice
tri ....... triangular waveform
Sin ..... Sinus ... sinusoidal waveform (the standard setting for a low-noise,
stable arc)
rEc ..... rectangular waveform with decreased edge steepness, for reducing the
noise-levels as against those that occur with the 100% rectangular
waveform
OFF ... 100% rectangular waveform (stable but loud arc)
tri ....... triangular waveform (recommended for welding fillet-welds)
Sin ..... Sinus ... sinusoidal waveform
rEc ..... rectangular waveform with decreased edge steepness, for reducing the
noise-levels as against those that occur with the 100% rectangular
waveform
OFF ... 100% rectangular waveform (stable but loud arc)
