Connections
Changing the camera
numbers
The camera numbers which have been set by "Auto IP
setting" can be changed.
They are changed by replacing the IP addresses of the
current camera numbers with the IP addresses of the
camera numbers to be changed.
1
On the [SYSTEM] menu, select
[CAM ASSIGN], and display [CAM1] to
[CAM100]. Then select the camera number
to be changed.
2
Select the IP address of the remote
camera for the selected camera number.
The tally indicator of the remote camera
corresponding to the selected IP address lights.
Operate the PAN/TILT lever, and check whether
the camera whose camera number is to be
changed is being moved.
The IP address that can be selected is the IP
address of the camera number which has been
set for "Network" for the [CAM1] to [CAM100] item
of [CAMERA CTL] on the [SYSTEM] menu.
3
Press the F2 dial to enter the IP address.
The IP addresses for the camera number of the
change destination and for the camera number of
the change source are switched over.
1.CAM1
192.168.000.100
Note
When "ASSIGN" is displayed for the [CAM1]
to [CAM100] item of [CAM ASSIGN] on the
[SYSTEM] menu, the CAMERA STATUS/
SELECTION buttons cannot be operated, and the
camera operations (IRIS, FOCUS, PT, ZOOM and
CAMERA OSD) cannot be controlled.
All manuals and user guides at all-guides.com
Changing the IP address of
The IP address of the switcher which was set by "Auto
IP setting" can be changed.
1
Clearing the IP address
All the IP address control tables which have been set
can be cleared together.
1
The "Serial" settings are not cleared.
▼
34 (E)
the switcher
On the [SYSTEM] menu, select [SW IP
ADR], and display [IP:SW]. Then change
the IP address.
control tables
On the [SYSTEM] menu, select [AUTO
SETUP], and display [AUTO SETUP].
Then select "ALL CLEAR", and press the
F2 dial to clear all the tables.
1.AUTO SETUP
ALL CLEAR
