Connections
 Example of serial connections 
 Connection with the AW-HE50 
AW-RP50
SIGNAL GND
TO PAN/TILT HEAD
TALLY/GPI 5 4 3 2
 Connection with the AW-HE100 
AW-RP50
SIGNAL GND
TO PAN/TILT HEAD
5 4 3
TALLY/GPI
All manuals and user guides at all-guides.com
Remote camera control signal

LAN cable
POWER
ON
12V IN
1 LAN
BOOT
SV NM
1: Use straight cables (category 5 or above) for these connections.
2: The multi-interface cable (AW-CA20T6G) is required for the
serial connection with the AW-HE50.
Remote camera control signal

LAN cable
POWER
ON
12V IN
2 1 LAN
BOOT
SV NM
: Use straight cables (category 5 or above) for these connections.
AW-HE50
2
RJ-45 relay
adapter
OUT
IN
V
PR
PB
Y
Multi-Interface Cable
AW-CA20T6G
AW-HE100
22 (E)
Monitor
Monitor
