Connections
3
Turn the F2 dial, select "Yes", and then
press the F2 dial.
This starts the "Auto IP setting" process.
When "Auto IP setting" has been initiated, the
progress is shown by the number of displayed
dots which are reduced one by one.
AUTO SETUP
When all the operations have been completed
successfully, "COMPLETE!" is displayed.
AUTO SETUP
The remote cameras can now be operated from
the unit.
The function for linking the switcher with the unit
becomes available for use at this point.
Memo
The "IP Duplication!" message is displayed if there
is duplication between the IP addresses of the
devices in operation and the IP addresses of the
additional remote cameras to be introduced.
The IP addresses are not set for those remote
cameras whose IP addresses are in duplication.
AUTO SETUP
IP Duplication!
Check the IP addresses, and then retry the "Auto IP
setting" operation.
If the IP addresses were not set successfully,
"SET UP ERR!" is displayed.
AUTO SETUP
SET UP ERR!
The cause of the problem is likely a network
malfunction.
Check the connection status of the hub and
LAN cables, and then retry the "Auto IP setting"
operation.
All manuals and user guides at all-guides.com
COMPLETE!
32 (E)
