1.3 Machine overview (from serial no. AI00967)
1 Boom light
2 Boom
3 Stick
4 Track
5 Travel gear
6 Stabilizer blade
7 Handhold
8 Lifting eye for loading/tying down the machine
9 Engine cover
10 Storage bin for Operator's Manual
11 Lock lever
12 ROPS rollbar (option)
13 Shatter protection (option)
3 2
7 13
6 4 5
Fig. 2: Machine outside views
